Specification
⌾ Magnification：1-6 x
⌾ Objective Lens Diameter：24 mm
⌾ Eye Relief：4 inches
⌾ Field of View：115.2-20.5 ft/100yds
⌾ Tube Size：30 mm
⌾ Turret Style：Low Capped
⌾ Adjustment Graduation：1/2 MOA
⌾ Travel Per Rotation：50 MOA
⌾ Max Elevation Adjustment：150 MOA
⌾ Max Windage Adjustment：150 MOA
⌾ Parallax Setting：100 yards
⌾ Length：10.1 inches
⌾ Weight：21.5 oz
OPTICAL FEATURES
⌾ APO System： Index-matched lenses correct color across the entire visual spectrum.
⌾ Optically Indexed Lenses： Optimize image sharpness and brightness from edge to edge.
⌾ HD Lens Elements： Premium extra-low dispersion glass delivers the ultimate in resolution and color fidelity, resulting in high-definition images.
⌾ XR™ Plus Fully Multi-Coated：Ultimate anti-reflective coatings on all air-to-glass surfaces provide maximum light transmission for peak clarity and the pinnacle of low-light performance.
⌾ Plasma Tech：Cutting edge coating application process provides unparalleled coating durability and performance.
⌾ Second Focal Plane Reticle：Scale of reticle maintains the same ideally-sized appearance. Listed reticle subtensions used for estimating range, holdover and wind drift correction are accurate at the highest magnification.
⌾ Illuminated Center Dot：Daylight bright illuminated center dot provides a precise point-of-aim in all lighting conditions.
⌾ Locking Illumination： Locks illumination at preferred setting.
⌾ Glass-Etched Reticle：Allows for intricate reticle design. Protected between two layers of glass for optimum durability and reliability.
CONSTRUCTION FEATURES
⌾ Tube Size：30 mm diameter provides maximized internal adjustment and strength.
⌾ Single-Piece Tube：Maximizes alignment for improved accuracy and optimum visual performance, as well as ensures strength and waterproofness.
⌾ Aircraft-Grade Aluminum：Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
⌾ Waterproof：O-ring seals prevent moisture, dust and debris from penetrating for reliable performance in all environments.
⌾ Fogproof： Argon gas purging prevents internal fogging over a wide range of temperatures.
⌾ Shockproof：Rugged construction withstands recoil and impact.
⌾ Hard Anodized Finish：Highly durable hard-coat anodization provides a low-glare matte surface and helps camouflage the shooter's position.
⌾ ArmorTek ：Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
⌾ Large Diameter Turrets：Provide fast, accurate and easily read elevation and windage adjustments. Caps provide external protection for turret.
NTERNAL MECHANISM DESIGN FEATURES
⌾ Friction Reduction System： Heat-treated, hardened-steel pad floats on the end of the turret screw and interfaces with a hardened steel ring on the erector tube for steel-on-steel contact. Prevents galling or deformation of the erector screw contact point for superior durability and.
⌾ Turret Screws：Provides low-friction, wear-resistant performance: precision-machined from a silicon-brass alloy and treated with an advanced dry-film lubricant. Turret screw threads are precision machined to sub-2 micron tolerances (less than 78-millionths of an inch).
⌾ Erector Tube System：Precision-machined from aircraft grade aluminum with anti-galling properties for a lighter weight,strong, durable tube. Stainless Steel offset coil spring erector biasing system withstands much higher stresses than traditional flat erector springs and al.
